PRODUCTS
Power Amplifiers
PRODUCTS Power Amplifiers
20 W High-Efficiency Power Amplifiers
| Part Number | Frequency Range [GHz] | EVAL Board Availability |
|---|---|---|
| ICASP3338-20 | 3.3 - 3.8 | Contact Us |
| ICASP3338-20A* | 3.3 - 3.8 | Contact Us |
| ICASP3540-20A* | 3.45 - 4.0 | Contact Us |
| ICASP4450-20A* | 4.4 - 5.0 | Contact Us |
*Coming Soon
Key Product Line Characteristics
- 33 dBm (2 W) average output power at 9.5 dB PAR
- Ultra rugged: can withstand 10:1 VSWR
- -50 dBc ACLR with DPD (33 dBm, 9.5 dB PAR)
- Wide bandwidth: 400 MHz IBW
- High efficiency: > 40% PAE
- 28 V operation (GaN)
- 6 x 10 mm2 package pin-to-pin compatible family
- 50 Ω in/out
